Single Ear Hose Clamp - Zero Leak - 9.6-11.3mm - 304SS
Description
HCL’s Zero Leak Ear clamp (O-Clip) is ideal for rubber and PVC hoses. The steel hose clamp forms a complete circle, removing the possibility of leakage. It is quick and easy to assemble, has a low profile design and is manufactured from corrosion resistant Stainless Steel 304 or W4. The Zero leak metal hose clip is also known sometimes as a low profile hose clamp.
Downloads
Product Specifications
- Diameter Range (A) mm9.6 - 11.3
- Diameter Range (A) inch0.38 - 0.44
- Band Width (B) mm - inch5.0 - 0.20
- Band Thickness (C) mm - inch0.5 - 0.02
- Band/Housing Material W4 Stainless Steel AISI 304
- Manufactured By Clamp (Tridon)
- Manufactured According toDIN3017
- Hazardous Goods No
- RoHS Compliant Yes
Features
- Manufactured to DIN3017 Standard
- Smooth Underside
- Bevelled Edges Protect Hose
- Exclusive Housing Design
